ONECLICK F1
Negotiable Min Order Quantity Unit
- Required Quantity
-
- Place of Origin
- Payment Terms
- Negotiable
- Production method
- Negotiable
- Shipping / Lead Time
- Negotiable / Negotiable
- Category
- Card Readers & Adapters , POS Systems
E2S Corp Co,. Ltd
- Verified Certificate
-
10
| Product name | ONECLICK F1 | Certification | - |
|---|---|---|---|
| Category |
Card Readers & Adapters
POS Systems |
Ingredients | - |
| Keyword | eft pos , handheld credit card terminal , mobile eft pos , wireless eft pos | Unit Size | - |
| Brand name | - | Unit Weigh | - |
| origin | Stock | - | |
| Supply type | - | HS code | - |
Product Information
The Most Advanced and Innovated ETF-POS
SPECIFICATION
| ONECLICK F1 provides many advantages for companies who need solutions for payment & value-added services - including credit, debit, smart cards, prepaid, lottery, gift & proprietary cards. The terminal suits markets like delivery, conventions, stadium, insurance, transportation services, after services, traveling sales, outdoor sales & services, taxi and others. |  |
| Processor & Operating System | Smart Card | ||
| Microprocessor | Cortex-ARM 32Bit RISC CPU | ISO7816,T=0,T=1,EMV LEVEL1 | |
| Operation system | RTOS | PSAM | |
| Memory | ISO7816,T=0,T=1, SAM Socket: 2EA | ||
| Flash Memory | 8MByte Nor-Flash | Peripheral Port | |
| RAM | 768KByte SRAM | RS-232 port support | |
| Display | USB 2.0 HOST | ||
| 128x64 pixels, TFT COLOR LCD | Wireless Modem (Option) | ||
| LCD Back Light | Built in CDMA or LTE , GSM/GPRS,3G available (optional) | ||
| Touch Panel | Dimensions | ||
| Touch Screen 4wire glare Type | 79mm(W) X 144mm(L) X48mm(H) | ||
| Magnetic Card Reader | Power | ||
| Magnetic stripe ISO7811,Track II,High Coercivity,Bi-Directional. | Input : DC 8.4V , 600mA | ||
| Printer | Environmental | ||
| Thermal graphical printer,Max 384, 58mm wide paper | Operating Temperature : -20°~ 80 | ||
| Improved easy open & easy load mechanism | Storage Temperature :-30°~90° | ||
| NFC | Humidity : 5% to 95% | ||
| Audio | |||
Competitive Features
- 1 years Warranty (The warranty period can be also extended more by a separate agreement.)
- Long term life time support up to 5 years
- Long term experiences and know-how accumulated in the fields since 2007.
- Various options: Built-in wireless such as GSM/GPRS/3G/LTE, Bluetooth, Wi-Fi, NFC, RFID and others and extended serial/digital inputs and outputs, etc.
- ONECLICK SDK: Provides developers with a convenient and effective way to incorporate credit cards into their solutions.
- Customization or OEM/ODM is available
- Product Info Attached File
B2B Trade
| Price (FOB) | Negotiable | transportation | - |
|---|---|---|---|
| MOQ | Negotiable | Leadtime | Negotiable |
| Payment Options | Negotiable | Shipping time | Negotiable |
- President
- In Suk Kim
- Address
- 2F, Sincere building, 332-34,Gochun-Dong, Uiwang-City, Gyounggi-Do,Korea
- Product Category
- Card Readers & Adapters,Financial Equipment,POS Systems
- No. of Total Employees
- 1-50
- Company introduction
-
As one of the most popular manufacturers of ETF-POS in Korea.EES Corp Co., Ltd was founded in 2007 in the name of Enterprise Electronic Service for providing payment terminal. E2S Corp Co,. Ltd has kept developing and introducing new products to the Market gaining good reputations from customers in the world as a worldwide leader of ETF-POS systems, E2S Corp Co,. Ltd operates from manufacturing and development as a your partner. Our mission is to service the full spectrum of retailers by offering the highest quality at the most competitive prices. E2S'ONCLIK products are the most reliable POS Terminals on the market today. Backed by a generous warranty, all products are manufactured to the highest quality standards. Thank you for visiting our website. E2S Corp Co., Ltd invites your inquiries. An authorized sales and service representative stands ready to support all of your POS Terminal needs. E2S Corp Co., Ltd has openings for additional sales and service organizations to support the rapid growth of our POS Solutions. Please contact us to find out how E2S Corp Co.,Ltd can delight your retail merchants with our line of ONCLICK card payment terminals.
